| Inlet & Outlet Size | 50 mm (2") | 80 mm (3") |
| Rated Speed | 650 RPM | 550 RPM |
| Flow Rate | 300 L/min | 860 L/min |
| Working Pressure | 0.345 MPa | 0.345 MPa |
| 5m Self-priming Time | 15 s | 20 s |
| Metering Accuracy | ≤ ±0.2% | ≤ ±0.2% |
| Repeatability | ≤ 0.1% | ≤ 0.1% |
| Operating Voltage | AC 380V | AC 380V |
| Motor Power | 2.2 kW | 7.5 kW |
| Overall Dimensions (L × W × H) | 1300 mm × 740 mm × 1130 mm | 1730 mm × 930 mm × 1130 mm |
The pump unit is equipped with a high-performance self-priming impeller pump and an integrated M80C flow meter. It can monitor the flow data in real time, providing precise support for process control and metering management. An independent explosion-proof control cabinet is also equipped.
Supports personalized customization
